PLEASE NOTE Price is for one motor
Level up to a premium
motor refined for high performance electric skateboarding.
Designed for electric skateboarding.
We took everything we learnt about electric motors and worked closely with our manufacturing partners to make specific improvements that take this motor to a whole new level.
RIDER DYLAN BELL
Enjoy an improved skate feeling.
With ultra low rolling resistance this motor free rolls better than any other motor we’ve tested.
A longer life for your motors.
Our unique quad bearing design ensures a long lifespan with the high radial loads placed on esk8 motors.
Serviceable bearings means easy maintentance with simple tools.
Simply swap your bearings out at the end of thier lifespan rather than discarding the entire motor.
More range through improved efficiency.
Good magnetic design and low friction helps get the most out of your battery. Overall range can be increased by up to 20% after changing to our motors.
Active cooling for maximum performance.
Centrifugal blower fins evacuate air from the rear of the motor, drawing in cool air through the mesh protected intakes, keeping the coils and magnets cool.
Radium 6485's running in Square Wave Mode for that Tie Fighter sound!
RIDER DYLAN BELL
FEATURES
- Ultra quiet FOC operation
- Ultra low rolling resistance
- Replaceable quad bearings
- Dust sealed exterior bearing
- Front mounted sensor PCB for the most reliable sensor operation
- High efficiency for maximum range
- Active cooling system
- Mesh protected air intakes
SPECIFICATIONS
- Dyno verified peak power - 8397W (245kv/48V), 7026W (205kv/48V)
- 10-20S Voltage
- 64mm diameter, 85mm length
- Curved N45UH magnets rated to 180C
- Battle hardened (magnets reinforced with additional epoxy)
- Serviceable quad NMB bearings
- 2.5mm thick steel rotor for impact protection and improved magnetic flux path
- Cooling system with mesh protected air intakes
- Front mounted PCB for best sensor performance
- Multi-core flexible Teflon hall sensor wires with 2.0mm JST connector (vesc plug & play), 40cm length
- Red 12awg silicone phase wires (30cm) with 4mm bullets
- 8mm shaft with keyway, 45mm length
- 44mm mounting pattern (adapters for 30mm Lacroix/SRB 3-Link pattern sold separately)
- Maximum operating temperature of 100C
- Each motor weighs 1.1kg
12 Month warranty *Conditions apply
